EN71-1 Toys Dynamic Strength Tester for Proformance of Toys Rides

Test Principle

This instrument is mainly used for test the proformance of rides at the speed of toys 2m / s to strike 50x50mm obstruct. The machine simulation children riding tricycle operation state, put on the load on the sample and use 2 m/s speed to strike a piece of 50 x50mm obstacles block.After testing to check sample structure and performance if are in good condition or not

A load is secured to the toy, and articulated arms with the elbow joints in a downward position are attached to
the steering wheel or handlebars if the toy is so equipped. The toy is driven three times into a non-resilient
step.
Determine whether the toy continues to conform to relevant requirements of this European Standard.

Test standards

EN71-1-2011-8.22

ASTM F963, clause 8.20

ISO 8142-1-2012-5.27

GB 6675-2014-5.24.4
